型号 | 有效容积 (m) | 槽体尺寸 (m) | 叶轮 | 安装功率 (kw) | 鼓风机风压 (kpa) | 每槽空气耗量 (m/min) | 生产能力 (m/min) | 每槽参考重量 (kg) | |
直径 (m) | 线速度 (m/S) | ||||||||
KYF-2 | 1.30x1.30x1.25 | 0.42 | 5.30 | 5.5 | >16 | 0-3 | 0.5-2 | 1868 | |
XCF-2 | 0.47 | 7.50 | 7.5 | 0.5-1 | 1935 | ||||
KYF-3 | 3 | 1.60x1.60x1,40 | 0.48 | 5.50 | 7.5 | ≥18 | 0-5 | 0.7-3 | 2074 |
XCF-3 | 0.54 | 7.50 | 15 | 0.7-1.5 | 2172 | ||||
KYF-4 | 4 | 1.80x1.80x1.50 | 0.55 | 5.76 | 11 | P19.8 | 0-6 | 1-4 | 2488 |
XCF-4 | 0.62 | 7.30 | 18.5 | 1-2 | 2730 | ||||
KYF-8 | 8 | 2.20x2.20x1.95 | 0.63 | 6.00 | 15 | ≥19.8 | 0-10 | 2-8 | 3568 |
XCF-8 | 0.72 | 7.50 | 30 | 2-4 | 3882 | ||||
KYF-16 | 16 | 2.80x2.80x2.40 | 0.74 | 6.7 | 30 | ≥25.5 | 0-15 | 4-16 | 6928 |
XCF-16 | 0.86 | 7.6 | 37 | 4-8 | 7545 | ||||
KYF-24 | 24 | 3.10x3.10x2.90 | 0.80 | 6.25 | 37 | ≥30 | 0-17 | 4-24 | 9820 |
XCF-24 | 0.95 | 7.6 | 45 | 4-12 | 10820 | ||||
KYF--38 | 38 | 3.60x3.60x3.40 | 0.90 | 6.90 | 45 | ≥34.3 | 0-25 | 8-38 | 10136 |
XCF-38 | 1.05 | 8.15 | 75 | 8-19 | 12352 | ||||
